Adjustable bend element 60 A4
Item no. 6225484 | EAN 4012196567348
- Product description
-
Product descriptionAdjustable bend element with welded rung for use in cable ladder types with a side height of 60 mm.
-
- Technical data
-
Technical data
Bend (angle) Adjustable Change of direction Vertical, rising/falling Colour stainless steel Connector version Integrated connector Dimension 60x400 Hinged no Maintain electrical functions no Material Stainless steel 1.4401 Rail thickness 1,5 mm Rustproof steel, pickled no Side perforation no Side rail version Flat profile Surface Bright, treated Version of the rungs Profile perforated Wide-span version no Dimensions
Dimension B 400 mm Dimension R 400 mm Height 60 mm Width 400 mm CO2 footprint (Product Carbon Footprint)
CO2 Footprint (GWP) Cradle-to-Gate 7,8838 kg CO2e / 1 Piece CO₂ Footprint (GWP) 7,8838 kg CO₂e Declared Unit (LCA) Units Declared Unit Quantity (LCA) 1 Determination date of CO2 value 2025-05-14T00:00:00.000+0200 - All types
-
Mounting accessories
Products Types Item no. Quantity SSU
Adjustable connector A4
LGVG 60 A4 6208932 10 piece - Downloads
-
Data sheet LGBE 640 A4 / 6225484 , 0.18MB , pdfEU declaration of conformity LGBE 640 A4 / 6225484 , 0.10MB , pdfUK Declaration of Conformity LGBE 640 A4 / 6225484 , 0.09MB , pdfREACH Declaration of conformity LGBE 640 A4 / 6225484 , 0.12MB , pdfRoHS Declaration of conformity LGBE 640 A4 / 6225484 , 0.13MB , pdfMounting instructions Mounting instructions, cable ladder systems , 6.45MB , pdfMounting instructions General information on the mounting , 2.65MB , pdf
