Centre suspension for cable tray, side height 60 mm, black

Item no. / Types

Length

Width

Hole diameter

Dimension B

Colour

Product description

Product description

Centre suspension for cable trays with rolled side rail of side height 60 mm. Black coated.

Technical data

Adjustable	no
Colour	Jet black; RAL 9005
Dimension	B100mm
F in kN	1,3 kN
for width max.	100 mm
for width min.	100
Hole diameter	10,5 mm
Maintain electrical functions	yes

Material	Steel
Suitable for cable ladder	no
Suitable for cable tray	yes
Suitable for mesh cable tray	no
Suitable for metric threaded rod	10
Surface	PES135 - Polyester
Version for	Suspended

CO2 Footprint (GWP) Cradle-to-Gate	0,0081 kg CO2e / 1 Piece
CO₂ Footprint (GWP)	0,0081 kg CO₂e
Declared Unit (LCA)	Units

Declared Unit Quantity (LCA)	1
Determination date of CO2 value	2025-05-27T00:00:00.000+0200

All types

All types

Types	Length	Width	Hole diameter	Dimension B	Colour	Item no.	Quantity	SSU
MAH 60 100 FSKSW	40 mm	100 mm	10.5 mm	94 mm	Jet black; RAL 9005	6358740	piece	1 piece
MAH 60 200 FSKSW	40 mm	200 mm	10.5 mm	195 mm	Jet black; RAL 9005	6358742	piece	1 piece
MAH 60 300 FSKSW	40 mm	300 mm	10.5 mm	295 mm	Jet black; RAL 9005	6358744	piece	1 piece
MAH 60 400 FSKSW	40 mm	400 mm	10.5 mm	395 mm	Jet black; RAL 9005	6358746	piece	1 piece
AHB 100 FTK SW	127 mm	180 mm	0.6 mm	-	100	6363875	piece	1 piece
AHB 200 FTK SW	231 mm	180 mm	0.6 mm	-	200	6363877	piece	1 piece
AHB 300 FTK SW	331 mm	180 mm	0.35 mm	-	300	6363878	piece	1 piece
AHB 400 FTK SW	431 mm	180 mm	0.2 mm	-	400	6363879	piece	1 piece
